FTTH Drop Cable Production: Manufacturing Process Explained
Surprising fact: over seventy percent of new U.S. broadband builds now depend on fiber networks that require high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment runs full-cycle Fiber cable sheathing line manufacturing, from selecting brand fibers like Fujikura or Corning SMF-28e to final test reports that guarantee full quality assurance.
Our FTTH drop designs fit overhead, underground, and direct-buried installation, with LSZH, polyvinyl chloride (PVC), and polyethylene (PE) jacket options and configurations from 1–4 cores. We offer OS1/OS2 and OM2–OM4 grades plus G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and logo printing.
Automation and high-precision equipment stabilize line speed and repeatability high. Typical lead times are four to five days for orders < 100 km and seven to ten days for < 500 km, with an MOQ of 1 km and warranty for free replacement on quality issues.
Continue to learn how materials plus testing and support work together to reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment provides end-to-end manufacturing and lab testing for U.S. deployments.
- Multiple jacket choices and fiber grades cover different install environments.
- Automated lines and machines deliver consistent quality and stable optical performance.
- Quick lead times, low MOQ, and brand fiber options support reliable procurement planning.
- Complete reports and after-sales warranty back product reliability and documentation needs.
FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment provides tailored drop solutions with full test documentation.
As a specialized maker and supplier, Shanghai Weiye OFC Equipment combines purpose-built equipment with tight material control. We provide customized service and products for single-family and MDU rollouts. Every order includes full QA coverage and full test reports.
Our lab conducts high-temperature, salt spray, and vibration testing to verify durability. Jacket options cover LSZH, PVC, and PE. Designs include bow-type flat and figure-8/self-supporting styles and support brand fibers such as Fujikura and Corning® SMF-28e.
- Controlled production lines and in-process checks for auditable shipments.
- Technical support for specs, trials, and ramp to volume.
- Modern fixtures and calibration reduce variability so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are aligned to network specifications, combining brand fiber choices with disciplined test flows.
Fiber Selection & Brand Options
We match fiber draw tower to minimum bend radius, loss, and deployment type. Options include OS1/OS2 and OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura® and Corning® SMF-28e are available to meet procurement standards.
Strength Member Options
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is ideal where non-conductivity is necessary. Steel wire adds tensile strength for longer aerial spans and bonding/grounding needs.
Extrusion & Process Control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Closed-loop control of extruder temperature and capstan speed stabilizes line speed and critical dimensions.
| Component | FRP | Steel wire |
|---|---|---|
| Primary use | Electrical isolation | Aerial spans, high tensile |
| Key benefit | Light, non-corrosive | High strength |
| Installation note | Easier terminations | Requires grounding |
In-Process and Final Testing
Inline geometry and concentricity checks operate in-line. Final optical tests verify loss and return loss. Each order ships with a full test report and lab results from high heat, salt-spray, and vibration tests to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Lot records and FAI approvals provide traceability and compliance for U.S. projects.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a compact portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and stable optical performance.
The flat bow-type drop keeps a small footprint for risers/ducts. It keeps bend loss low for easy routing in hallways and MDUs.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs use a support messenger to carry tensile loads. Choose dielectric FRP for non-conductive runs or steel messenger when bonding and extra tensile strength are required.
Strength member and core layouts
We offer both dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and flat unitube types balance crush resistance and fiber ribbone line for quick termination.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each family is validated for mechanical/optical performance before shipment.
| Type | Application | Strength member | Jacket |
|---|---|---|---|
| Flat bow-type | Indoor risers, MDUs | FRP (dielectric) | LSZH |
| Self-supporting (aerial) | Overhead spans | FRP/Steel | PE |
| Central loose-tube | Higher-count builds | FRP | LSZH/PE |
| Flat unitube | Low count, quick strip | FRP or steel | LSZH/PE |
Production line equipment that ensures quality and speed
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for drop patch preparation.
Our production line integrates automated machines that cut/strip drop cords to raise throughput and cut labor variability.
The CLX-BPO2 automated stripper runs under PLC and photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Auto Cut & Strip Capabilities
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise stub lengths. Cylinder-driven actuators deliver fast, repeatable motion and minimize downtime.
PLC/photoelectric control for precision and repeatability
PLC logic and photoelectric sensors deliver precise positioning and feedback control. Inline checks feed control charts so operators can adjust drifts before defects grow.
| Feature | Capability | Result |
|---|---|---|
| Machine | Auto-strip, ~1.5 s cycle | High throughput |
| Drive | Cylinder-based | High speed and reliability |
| Materials | LSZH/PVC; FRP/steel | Clean, accurate preps |
| Control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic loading keep the line clean.
- PCPs document calibration and key parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without sacrificing accuracy.
CLX-BPO2 auto-stripping machine capabilities in our line
The CLX-BPO2 provides industrial-grade strip/trim to our line, reducing cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize prep quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC/photoelectric control enable precise detection and repeatable actuation. That control keeps strip and stub lengths within tight tolerances.
Cycle time and throughput
Typical operation speed is ~1.5 seconds per cycle. This translates to steady throughput under continuous line conditions.
Supported jacket and reserved strength lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5–35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to match common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Customized cutters are offered for non-standard cross-sections to preserve precision.
- Automatic waste ejection and sensor start reduce idle time.
- Small footprint (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg mass ease integration into workcells.
- Pneumatic cylinders and PLC/photoelectric control improve line reliability and reduce maintenance downtime.
| Specification | Value | Benefit |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | Supports high-volume runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Fits common connector processes |
| Reserved stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power/Size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1 to 4 cores with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 plus G.652D and G.657 variants to align with optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tags.
Jackets, Legends & Branding
Select LSZH/PVC/PE jackets to suit route and safety requirements. Custom print legends and logos support inventory and warranty tracking.
Lengths, Packaging & Special Builds
Standard reel lengths are 1 km, 2 km, and 4 km with tailored reels and packaging to fit storage/handling. Choose bow-type flat or self-supporting designs and steel wire or FRP strength members to meet span and isolation needs.
| Choice | Common choice | Advantage |
|---|---|---|
| Length | 1 / 2 / 4 km | Less staging, easier reels |
| Sheath | LSZH, PE, PVC | Indoor/Outdoor fit |
| Structure | Flat bow / Self-supporting | Flexible routing/span |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and delivers documentation that detail final specs for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab runs elevated-temperature exposure, salt fog corrosion, and mechanical vibration to qualify materials and assemblies. These tests simulate field stresses for indoor and outdoor use.
Per-Reel 100% Reports
Every fiber optic cable includes a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates prevent nonconforming shipments before they leave the factory.
Traceability & Compliance
Lot/batch records link tests to reels/serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include spec confirmation and formatted data for quick review.
- Continuous test trends drive preventive maintenance and improve long-term reliability.
| Test | Why | Result |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt-fog | Corrosion resistance | Outdoor suitability |
| Vibration | Mechanical robustness | Improved field reliability |
Pricing and cost drivers for FTTH drop cable
Budgeting for a drop run starts with fiber and jacket choices and is shaped by volume and customization.
Typical prices vary widely—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, reel length, and structural design.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber optic grade, jacket material, and the structural type chosen for deployment.
Self-supporting structures and steel members raise material and labor input. Custom sheath colors/logos/legends add setup time and impact pricing on small runs.
Length/Volume/Customization Impact
Longer reels and higher volume orders reduce unit cost. Small quantities often include setup charges and higher unit prices.
- Changeovers and special cutters increase lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets across phases.
| Factor | Price impact | Recommendation |
|---|---|---|
| Optical grade | High impact | Right-size spec to budget |
| Jacket type | Medium impact | Evaluate LSZH vs PE |
| Length/Volume | High impact | Consolidate runs to cut unit cost |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable windows cut downtime and help control cost when a rollout is underway.
Scheduling & Capacity Planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We plan capacity to match your rollout milestones and to keep deliveries on time.
The service team provides updates/tracking so installation teams know when reels arrive. For compressed schedules, we hold contingency capacity to accelerate critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects line setup such as wire/die adjustments that consume start-up material and scrap.
We review your length and staging plans to choose reel sizes that cut waste and handling. Batch releases can balance inventory with frequent, smaller deliveries to job sites.
Installation readiness and application scenarios
Site conditions dictate whether a self-supporting aerial, ducted pull, or direct burial is the best fit for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to manage sag/tension for long-term reliability.
Duct installations perform best with low-friction sheaths and crush-resistant builds so pulling does not damage fibers. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture barriers to protect the fiber core long-term.
Indoor Distribution and ONT
Indoor riser and plenum routes prefer LSZH to meet flame and smoke rules. Flat drop profiles strip cleanly and present controlled strength stubs for quick ONT termination.
We advise on steel vs FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware compatibility. Standardized prep from the production line shortens install time and reduces scrap.
| Deployment | Key feature | Field note |
|---|---|---|
| Overhead | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct burial | PE with moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH with tight-bend support | Maintain bend radius at wall penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That reduces callbacks, speeds activations, and reliable field performance for your system.
End-to-end support and after-sales service
Our team coordinates testing, scheduling, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements capture through approved drawings and pilot builds. We deliver documentation templates and clear install notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to help QA acceptance.
- Round-the-clock availability for status and technical support.
- Warranty includes free replacement for confirmed quality issues.
- Coordination of line schedules for expedites and urgent changes.
- Config control so shipped items match agreed requirements every time.
| Support area | What we do | Benefit |
|---|---|---|
| Engineering | Spec review & pre-production builds | Reduced field issues |
| Testing | Lab + 100% reports | Traceable quality |
| After-sales | Fast replace + RCA | Minimized downtime |
Conclusion
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented lab trials to support field acceptance in the United States.
A robust production line, including CLX-BPO2 prep assets, reduces variability and shortens turnaround. Our equipment set standardize strip/stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance performance and cost to maximize service life. Dedicated support covers scheduling/logistics/after-sales so your deployment stays on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every shipment with lab validation and responsive support.
